2006 Nissan Frontier Brake Controller Installation
Please visit my general install page for overall instructions
"Standard" Wire colors to the controller (Tekonsha and others):
-
- Tekonsha and others
- Function
-
- Black
- Battery Positive to controller
-
- White
- Negative Ground for Controller
-
- Blue
- Brake feed from controller to Trailer plug at back of truck
-
- Red
- Tap into truck Brake light switch signal to tell controller to apply brakes
Remember, the above colors are just a GUIDE. your colors may be different, read the instructions!

Most Frontier Pickup's from years 2005-2014 come with factory pre-wired for a brake controller and the model above did.
Above is a picture of the plug located under the dash, sort of above the gas pedal.

Above is a picture of the plug located under the dash, sort of above the gas pedal.
